CHS398100HCXViN CHS-HCX2 Model Series
With Rinnais new Demand Duo H-Series, reliable hot water comes in a high-performance, high-efficiency package that also reduces cost of ownership. Rinnais hybrid technology is unlike anything else on the market, ensuring a longer service life than high-efficiency tanks, while also saving valuable commercial space. The tankless engines for the Demand Duo 2V are stacked vertically to deliver redundancy and eliminate "no hot water" events that affect profitability.
- Uniform Energy Factor (UEF): 0.98
- 15,000 BTU (minimum)
398,000 BTU (maximum) - Indoor
- Warranty
-
33 in. X 79 in. X 40 in. (838 mm x 2007 mm x 1016 mm)
Supply Connections
Connection Connection Size Gas 1-1/2"MNPT Cold Inlet 1-1/2" MNPT / (38 mm) Hot Outlet 1-1/2"MNPT Condensate Drain 1 -
Product Depth 40 inch / (1016 mm) Product Height 79 inch (2007 mm) Product Width 33 inch / (838 mm) Product Weight 530 lb / (241 kg) Gas Type Natural Gas Installation Type Indoor Recirculation Capable Yes Uniform Energy Factor (UEF) 0.98 Wi-Fi Capable Yes SCAQMD Approved Ultra Low NOx Warranty information is available in the Installation & Owner Manual.
-
